Vendron Box

VENDRON BOX 4

Vendron Box 4

Smart Vending Software
Vendron® 4, on Windows 10 IoT operating system, ready to connect to Vendron Cloud.

Memory & Storage
DDR3 2GB & SSD 32GB

Graphics
Integrated Intel® HD Graphics 400, 320MHz base frequency (up to 640MHz), support Full HD 1080p
– HDMI connector x 2

Vending Data Interface
MDB
Support direct interface to vending machines of various OEM globally
EVA-DTS / DEX / UCS (via COM port)

Dimension & Weight
190 x 150 x 29 mm
860g

CPU
Intel® Celeron® processor N3160 (Quad-core, 1.6GHz, up to 2.24GHz, 2M cache)

Interfaces
USB 3.0 x 2
USB 2.0 x 4
Mic In + Line Out x 1
LAN RJ45 x 3
(Gigabit Ethernet)
COM port x 2 (RS-232/485 on COM2)

Power Supply
DC +19V, 3.42A (Included AC Adaptor 100~240V)

Enclosure
Fanless Rugged Case

Wireless
WiFi
SIM card slot x 1 (for optional 3G/4G module for mobile connectivity)

Vendron Box Core 4

Smart Vending Software
Vendron® 4, on Windows 10 IoT 64-bit operating system, ready to connect to Vendron Cloud.

Memory & Storage
DDR4 8GB & SSD 64GB

Graphics
Intel® HD Graphics 620, 300MHz base frequency (up to 1.0GHz), support Ultra HD 4K resolution
-HDMI connector x 1
-DisplayPort connector x 1

Vending Data Interface
MDB
EVA-DTS / DEX / UCS (via COM port)
Support direct interface to vending machines of various OEM globally

Dimension & Weight
225 x 190 x 74 mm
2.5kg

CPU
Intel® CoreTM i5-7200U processor (2.50GHz, up to 3.10GHz, 3MB SmartCache)

Interfaces
USB 3.0 x 4
USB 2.0 x 4
COM port x 6 (RS-232 on COM1~4, RS-485 on COM5~6)
LAN RJ45 x 2 (Gigabit Ethernet)
Audio x 1 (Mic In + Line Out)

Power Supply
DC +12V, 5A (Included AC Adaptor 100~240V, 1.5A, 50/60Hz)

Enclosure
Fanless Rugged Case

Wireless
WiFi (Mobile connectivity can be added as a separate module)

VENDRON CUBE

Vendron Cube

Smart Vending Software
Vendron®, on Embedded Linux system, Ready to connect to Vendron Cloud.

Memory & Storage
DDR3 2GB & eMMC 32GB

Graphics
Integrated Intel® HD Graphics 400, 320MHz
base frequency (600MHz, dynamic max)
– support Full HD 1080p
– HDMI connector x 2

Vending Machine Interfaces
– Support most conventional or old vending machines of push button or keypad selection type
– Additional inputs and outputs for other switches and sensory inputs

Dimension & Weight
140 x 107 x 45 mm

CPU
Intel® Celeron® Processor N3060 (2.48GHz,2M cache)

Interfaces
USB 3.0 x 4
USB 2.0 x 1 (mUSB)
Mic In/Line out x 1
LAN RJ45 x 2
(Gigabit Ethernet)
COM port x 2 (RS-232)
SIM card slot x 1
Full size mini PCIe slot x 1
Half size mini PCIe slot x 1

Power Supply
DC +24V

Enclosure
Not Available

Wireless
WiFi
Mobile wireless module (4G LTE / 3G)

VENDROID BOX

Vendroid Box

Smart Vending Software
Vendron® 4, on Android 5.1 operating system, ready to connect to Vendron Cloud.

Memory & Storage
DDR3 2GB & eMMC 8GB

Graphics
Mali-T764 GPU, support Full HD 1080p
– HDMI connector x 1

Vending Data Interface
MDB
Support direct interface to vending machines of various OEM globally
EVA-DTS / DEX / UCS (via COM port)

Dimension & Weight
196 x 107 x 46 mm
750g

CPU
Rockchip® RK3288 processor (Quad-core Cortex-A17, up to 1.8GHz)

Interfaces
USB 2.0 x 4
COM port x 3 (RS-232)
LAN RJ45 x 1
(100M Ethernet)
Audio Out / Mic In x 1

Power Supply
DC +12V, 3A

Enclosure
Fanless Case

Wireless
WiFi
3G mobile connectivity
(SIM card slot x 1)
Bluetooh 4.0
